Horizontální obalový štítkovací stroj

Domov / Etiketovací stroje / Plochý štítkovací stroj / Horizontální obalový štítkovací stroj

Horizontální obalový štítkovací stroj

vodorovné ovíjení kolem zkumavkového etiketovacího stroje


1. Apply to food, pharmaceutic, daily chemical, stationery, plastic industries etc.

2. Mainly used to automatically stick adhesive label on cylinder or small conical products which is unable to be carried vertically, such as tube, cylinder bottle, water injection, conical tube etc. High labeling precision, stable work ability, neat, no wrinkle, no bubble.

3. Suit for single or similar diameter products, orbit unadjustable and Can be matched with bottle feeder, ribbon printer, date printer, etc

Technický parametr


Velikost označení(L) více 10 mm
(W) 110 - 100 mm
Vnitřní průměr válcování76 mm
Velikost produktu(D) 10 až 16 mm 16 až 26 mm 26 až 36 mm
(H) méně než 100 mm
Průměr vnějšího válce350 mm
Přesnost označování+ -1 mmZdroj napájeníAC220V 50 Hz 3kW
Rychlost označování40 - 150 (ks / min)
(vztahují se na velikost materiálu a štítku)
Velikost stroje(L) 2000 * (W) 1700 * (H) 1500 mm

Rychlé informace


Typ: Etiketovací stroj
Stav: Nový
Použití: Nápoje, chemikálie, komodity, potraviny, stroje a hardware, lékařské
Typ balení: Lahve
Balicí materiál: papír, plast
Automatická známka: Automaticky
Typ pohonu: Elektrické a vzduchové
Napětí: 110V / 220V
Příkon: 1,5 kW
Místo původu: Šanghaj, Čína (pevnina)
Název značky: NPACK
Rozměr (L * W * H): 2100 * 700 * 1000 mm
Hmotnost: 300 kg
Certifikace: GMP
Poskytuje poprodejní servis: Inženýři jsou k dispozici pro servis strojních zařízení v zahraničí
Název produktu: vodorovné ovíjení kolem etiketovacího stroje
Funkce: Označení zkumavky
Materiál: nerezová ocel S304
Rychlost označování: 60-150 lahví / min
Použití: horizontální značení
Výhoda: tým profesionální podpory

A horizontal wrap around tube labeling machine is a machine that is designed to wrap labels around cylindrical tubes with high efficiency and accuracy. This type of machine is ideal for labeling a wide range of products, including cosmetic tubes, toothpaste tubes, food containers, and other cylindrical products.

The machine is designed with a horizontal orientation, which enables it to handle large volumes of products in a compact and efficient manner. The labeling process starts with the product being fed into the machine, which then positions it in the correct position for labeling. The label is then applied to the product as it is rotating, ensuring a smooth and even application.

The machine is equipped with advanced features such as a touch screen control panel, which makes it easy to operate and adjust the settings. The control panel also provides real-time monitoring of the labeling process, enabling the operator to make any necessary adjustments to ensure consistent and accurate labeling.

The machine is also equipped with a high-speed labeling system, which can apply labels at speeds of up to 200 tubes per minute. This high speed capability ensures that the machine can keep up with the demands of a fast-paced production environment.

In addition, the machine is equipped with a built-in quality control system, which checks the accuracy of the labeling process and alerts the operator if any problems are detected. This ensures that the product is labeled with the correct information and meets all quality standards.

The horizontal wrap around tube labeling machine is also designed to be easy to maintain, with removable and replaceable components that can be quickly and easily replaced if needed. This helps to minimize downtime and reduce the cost of maintenance.

In conclusion, a horizontal wrap around tube labeling machine is a versatile and efficient labeling solution for a wide range of products. With its advanced features, high speed capabilities, and easy maintenance, it is an ideal choice for companies looking to improve the accuracy and efficiency of their labeling process.
